SLIDING DOORS

Lotus

• Profiles according to TS EN 12608-1 standard.
• Lower frame height according to similar sliding systems
• Larger window area, more spacious interior space. More daylight, extra view.
• Aesthetic lines.
• High moment of inertia and ability to make higher casement.
• Casement profile has a more rigid structure.
• Possibility to implement 4, 5, 20, 24, 26, 28 mm glass units, panelling and panels.

Technical Specifications

• Frame Profile Width : 122 mm
• Casement Profile Width : 45 mm
• Number of Cubicles (Frame) : 4
• Gasket : TPE Gray/ Black
• Glazing Bead : Single Claw – PCE Gasket
• Glass Thickness : 4, 5, 20, 24, 28 mm

Panorama HS76

The Window Profile System that adds the outdoors to your home and allows you to experience the view in the comfort of your home without making concessions to insulation. Special gaskets are used in Panorama HS 76 sliding system to provide an excellent level of thermal insulation, higher wind resistance, and waterproof compared to similar sliding systems. Thanks to its design, it offers easy operation and minimal view loss. It is possible to use both aluminium and PVC as the bottom frame.

Technical Specifications

• Frame Profile Width : 175 mm
• Casement Profile Width : 76 mm
• Number of Cubicles (Casement) : 6
• Gasket : TPE Gray/ Black
• Glazing Bead : Single Claw – PCE Gasket
• Glass Thickness : 4, 10, 20, 24, 26, 30, 32, 36, 39 mm
